QSC AD-S112sw 12" Weather Treated Woofer Passive Subwoofer

QSC AD-S112sw AcousticDesign 12" Weather Treated Woofer Passive Subwoofer

SKU #: AD-S112-SW
$982.00

Notify me when in stock

We'll let you know once this product is back in stock. Simply add your email address and click the "Notify Me" button. As soon as we have more you will receive a notification.

Item Backordered

Expected June 30, 2025

Only at IDJ NOW

Fast Shipping

Fast Shipping

Most products ship same-day

30-Day Price Protection

30-Day Price Protection

Find a lower price, you're covered.

8000+ Reviews

8000+ Reviews

95%+5-star reviews>

30-Day Returns

30-Day Returns

Don't Like it? Return most items.

12" Surface subwoofer, includes mounting yoke and weather input cup in black.

QSC AD-S112sw 12" Passive Subwoofer Features:

  • 12" weather treated woofer
  • TFR (Turbulent Flow Reduction) port provides optimal resonant tuning and high velocity air flow
  • Maximum peak SPL 121 dB
  • Suggested filter points: 32 Hz high-pass, 24 dB/octave Butterworth; 100 Hz low-pass, 24 dB/octave Butterworth
  • Included YMS12 yoke mount maximizes boundary plane coupling while reducing vibration transmission
  • Optional M10 Kit-C for additional installation versatility
  • Lightweight ABS enclosures offer long-term durability and lasting good looks
  • Sealed input panel cover and powder coated aluminum grilles for added weather resistance
  • Meets IEC60529 IP-54 for dust and splash resistance
  • Available in black (RAL 9011)
  • Complete EASE, CF2, CAD, and BIM information available online

QSC AD-S112sw Specifications
System DetailsAD-S112sw
Effective frequency range30 - 135 Hz
Rated noise power / voltage300 watts / 50 volts (rms)
Broadband Sensitivity90 dB SPL
Maximum continuous SPL115 dB
Maximum peak SPL121 dB
Rated impedance8 ohms
Recommended amplifier power
(loudspeaker "program" power)		600 watts
Transformer tapsn/a
HF transducer-
LF transducer12" weather resistant paper cone woofer,
2.5" / 64mm voice coil
Input connector typeEuroblock connector with parallel output terminals
Enclosure materialPainted ABS polymer
Grille materialPowder coated aluminum
Yoke materialPowder coated galvanized steel (included)
Enclosure Details
Ingress protectionIP-54
Operating environmentDesigned for indoor and outdoor use
TestingThe AD Series loudspeakers qualified for outdoor use using
the following tests:

  • Salt fog: MIL-STD-810G Method 509.5 for 100 hrs.
  • Humidity: MIL-STD-810G Method 507.5, Natural cycle B2, cyclic high RH for 7 days
  • High and low temperature: tested to QSC internal standards between -20° & 50° C
Product Dimensions
(HWD) inches		23.4 x 13.9 x 12.7
Product Dimensions
(HWD) mm		594 x 354 x 323
Net weight29 lb / 13.2 kg
Shipping weight43.1 lb / 19.6 kg
Shipping dimensions27.5" x 21.75" x 18.5" (698 x 552 x 470 mm)
Included accessoriesYMS12 yoke mounting system, Euroblock connector,
input panel cover

The AD-S112sw Box Includes:
(1) QSC AD-S112sw AcousticDesign 12" Weather Treated Woofer Passive Subwoofer
(1) YMS12 Yoke mounting system
(1) Euroblock connector
(1) Input panel cover
